Leeson C333 | Pump Motor 3/4HP, 3600RPM, 115/208-230V, Frame 56J, ODP
• Dimension Print Available Here
Product Details : Leeson C333 | Pump Motor 3/4HP, 3600RPM, 115/208-230V, Frame 56J, ODP
- Part No: C333
- Product Type: Pump Motor
- Category: Pump Motors
- Brand: Leeson/Marathon
- Frame: 56J
- Enclosure: ODP
- Horsepower (HP): 3/4
- Poles: 2
- RPM: 2500 to 3600
- Voltage: 115/208-230V
- Phase: 1
- Number Of Speeds: 1
- Frequency (Hz): 60
- Amps: 11.2/5.6
-
Features:
• CENTRIFUGAL PUMP (JET PUMP) MOTORS
• SINGLE PHASE, DRIP PROOF MOTORS
• Service factor, as noted
• Double sealed ball bearings, mechanically locked on shaft end
• Capacitor start/capacitor run design for higher efficiency, as noted
• Fixed CW rotation, viewed opposite shaft end
• Automatic reset thermal protector
• 56C = carbon steel shaft with key
• 56J = 416 stainless steel threaded shaft with slinger
• Drip cover not included, see accessories section
• UL recognized and CSA certified
• Model 5KC39QN3219X
For any information about products, please contact us.
*Photos for reference purposes only.
$80.00
Original: $266.66
-70%Leeson C333 | Pump Motor 3/4HP, 3600RPM, 115/208-230V, Frame 56J, ODP—
$266.66
$80.00Product Information
